With its round, harmonious shapes, ELIO imparts a feeling of comfort that brings to mind uncomplicated, everyday moments. And working with ELIO is just the same, because the functions of this fitting have been designed specifically with every possible requirement in mind, from washing vegetables to washing up: with an extending spray that comfortably reaches every area of the sink unit. Single lever mixer with profi spray set 235mm projection
Pivotable spout 360° Spout, end-piece with 20° rotation
Height of mixer 337mm Height up to profi spray set approx. 675 mm Height up to aerator 297mm
Hole diameter rinsing spray 30 mm Single-lever mixer hole diameter 35 mm M 24 x 1 aerator - male thread
Cartridge with ceramic discs Automatic spout/shower diverter
2 x M 10 x 1 x 420 mm high pressure hose 1 x M 10 x 1/2" x 420 mm high pressure hose Attachment tube with 185 mm fitting Suspended spray with stainless steel spring (can be pivoted and locked) 1750 mm metal shower hose for rinsing spray set Max. flow single-lever mixer 7.5 l/min at 3 bar flow pressure Sprayface with anti-scaling system Max. flow profi spray 6 l/min at 3 bar flow pressure Intrinsic protection against back flow. Recommended minimum flow pressure: 2.5 bar. |
